NTG-520N
Ren Thang Machine
NTG-520N
Pre-scored PCB Depaneling Machine - Roller slice
PCB V槽分板機
The NTG-520N is an advanced continuous multi-blade V-groove PCB depaneler featuring an extended infeed conveyor and synchronized cutting stations for multi-panel arrays. It delivers high-efficiency, burr-free separation in a single pass, ideal for demanding high-throughput SMT production lines.
Processing & Feature Tags
ENGINEERING SPECIFICATIONS
Machine Specifications & Performance
Processing Capacity 滾刀轉速可調；長度無限制
Power / Air Supply 110V/60Hz ; 220V/50Hz
Standard Tolerance 板厚 0.4 ~ 2.0 mm；內側寬 160 mm
Dimensions (L×W×H) 430(L) × 430(W) × 520(H) mm
Net Weight 36 kg
Catalog Page & Status
P.18, P.20 (Catalog_0018, Catalog_0020) • 在產 (Active)
【Key Machine Features & Advantages】
- Roller-slice pre-scored PCB depaneling machine engineered with a stress-free philosophy, eliminating bending stresses and solder joint micro-cracks.
- Features an upper-passive and lower-active round pizza-slider blade mechanism that smoothly follows the V-groove for burr-free cuts.
- Broad substrate compatibility: fully capable of depaneling both standard FR4 fiberglass boards and pre-scored metal-core aluminum PCBs.
- Generous component height clearances: accommodates components up to 35 mm high on the top side and 15 mm on the bottom side.
- Dual-axis precision calibration: blades are finely adjustable both in vertical height and horizontal alignment for exact V-groove centering.
- Standard feed direction from left to right, with an optional reversible dual-direction motor available upon request.
- Flexible processing envelope: handles PCB thicknesses of 0.4 ~ 2.0 mm (V-groove residual thickness approx. 1/3A), width up to 160 mm, with unlimited board length.
- Modular optional platforms: available with optional extended platform, extended & widened platform (168mm+), or motorized conveyor belt platform.
【Revision Notes】 板厚 0.4~2.0mm，V槽殘厚 1/3A，長度無限，寬度 160mm。零件限高：板上 35mm / 板下 15mm。適用鋁基板。
Lead Forming & Geometric Parameter Specifications
Unit: mm / Custom tooling available Dimension & Bending Schematic NTG-520N
Callouts match specifications in the table (Click image to enlarge)
| Code | Parameter | Standard Value / Range | Engineering Notes |
|---|---|---|---|
| PCB_THICK | PCB Thickness (A) | 0.4 ~ 2.0 mm (常用 0.8 ~ 2.0mm) | Standard applicable to FR4 fiberglass boards and aluminum substrates |
| PCB_LEN | Feasible PCB Length | 無限制 (Unlimited) | Continuous hob feeding, unlimited length |
| PCB_WIDTH | Feasible PCB Width | 內側最寬 160 mm (加裝寬版平台可達 168mm+) | Single or double side slitting |
| V_DEPTH_RATIO | Groove Depth & Leftover | 深度 B 與殘厚 C 各約 1/3 × A (30° V-Cut) | Standard 30-degree V-groove ratio |
| PCB_MATERIAL | Applicable PCB Material | Aluminum PCB available (適用鋁基板與玻纖板) | High thermal conductivity metal substrates and general circuit boards |
| PARTS_H_TOP | Height of Parts on PCB | 最大 35 mm (Max. 35mm) | Safe avoidance of large-sized capacitors and connectors |
| PARTS_H_BOT | Height of Parts under PCB | 最大 15 mm (Max. 15mm) | Safe space for bottom leads and chip components |
| FEED_DIR | Feeding Direction | 從左至右 (From Left to Right；可選購換用雙向馬達) | Clear direction, smooth operation |
| BLADE_SPEC | Blade Specification & Type | 上被動滾刀 + 下主動滾刀 (如披薩刀 Pizza Slider) | Round hob rolls along the shape and separates |
| OPERATION | Operation Method | 電源開關控制 (Power Switch) | Simple and intuitive switch activation |
| PLATFORM_OPT | PCB Supporting Platform | 可視需求加大訂製 (Extendable Platform) | Extended platform, extended and widened platform, conveyor belt platform |
