HC-1420
Ren Thang Machine
The HC-1420 is an anti-static PCB inspection conveyor table equipped with ESD-safe belts and dual-side operator inspection platforms. Featuring stepless speed control and optical board-stop sensors, it serves as a reliable buffer, visual check station, and transition link across SMT and DIP lines.
Processing & Feature Tags
ENGINEERING SPECIFICATIONS
Machine Specifications & Performance
Processing Capacity 每排 17 層掛鉤 (間距 65mm)，可承載多組 PCB 放置架儲存與廠內搬運
Power / Air Supply 免用動力 / 人工推行 (Manual Push Cart)
Standard Tolerance 防靜電表面阻抗 10³ ~ 10⁵ Ω/sq
Dimensions (L×W×H) 1420-M1: 490(L) × 510(W) × 1400(H) mm / 1420-M2: 490(L) × 750(W) × 1400(H) mm / 1420-S: 990(L) × 550/750(W) × 1420(H) mm
Net Weight 1420-M1: 18 kg / 1420-M2: 25 kg / 1420-S: 40 kg
Catalog Page & Status
P.11 (Catalog_0011 / HC-1420M1&S) • 在產 (Active)
【Key Machine Features & Advantages】
- ESD-Safe Anti-Static Belt & Grounding: Fully compliant ESD protection prevents electrostatic damage to sensitive PCBA.
- Dual-Sided Inspection Platforms: Ergonomic side tables provide ample space for visual inspection and manual rework.
- Electronic Stepless Speed Control: Smoothly synchronizes conveyor throughput with upstream/downstream equipment takt time.
- Integrated Infeed/Outfeed Optical Sensors: Supports manual/auto modes and optical board-stop queuing.
- Rigid Aluminum Extrusion Frame with Casters: Lightweight, durable chassis enables quick line repositioning and docking.
【Revision Notes】 提供單排輕巧型 (1420-M1, 1420-M2) 與雙排大容量型 (1420-S) 多款規格；可選配 HC-1 系列防靜電 PCB 放置架。
Lead Forming & Geometric Parameter Specifications
Unit: mm / Custom tooling available Dimension & Bending Schematic HC-1420
Callouts match specifications in the table (Click image to enlarge)
| Code | Parameter | Standard Value / Range | Engineering Notes |
|---|---|---|---|
| 1420-M1 | Single Column Standard (1420-M1) | 490(L) × 510(W) × 1400(H) mm / 淨重 18kg | 17-layer hooks (65mm spacing), the body is lightweight and does not take up space |
| 1420-M2 | Single Column Wide (1420-M2) | 490(L) × 750(W) × 1400(H) mm / 淨重 25kg | 17-layer hooks (65mm spacing), widens the storage space |
| 1420-S | Double Column Heavy-Duty (1420-S) | 990(L) × 550/750(W) × 1420(H) mm / 淨重 40kg | Double rows with large loading capacity, the first choice for semi-finished product storage and in-factory transportation |
| ESD_RES | Surface Resistance | 10³ ~ 10⁵ Ω/sq | PS conductive plate forming track, with excellent anti-static effect |
| HOOK_GAP | Hook Tiers & Pitch | 17 層掛鉤 / 間距 65 mm | Each row is equipped with 17 Layer hooks, vertical spacing of 65mm |
