CF-150
Ren Thang Machine
The CF-150 accommodates any free-standing loose radial components—including LEDs, electrolytic capacitors, and TO-220 packages—via a straight-through manual slide track. Hand-feeding eliminates bowl tooling constraints, while durable rotary shears deliver shock-free trimming ideal for high-mix low-volume production.
Processing & Feature Tags
ENGINEERING SPECIFICATIONS
Machine Specifications & Performance
Processing Capacity 9,000 pcs / Hour
Power / Air Supply 110V/60Hz ; 220V/50Hz
Standard Tolerance ±0.3mm
Dimensions (L×W×H) 260(L) x 260(W) x 400(H) mm
Net Weight 淨重: 10 kgs
Catalog Page & Status
P.01 • 在產 (Active)
【Key Machine Features & Advantages】
- Universal Stand-Up Radial Compatibility: Accommodates any free-standing loose radial components including LEDs, capacitors, TO-220 power devices, and transistors.
- Horizontal Manual Slide Feeding: Flat guide track design allows effortless hand-feeding of both miniature and large electronic components.
- Proprietary Rotary Shear Mechanism: Gentle cutting action minimizes mechanical shock and dramatically extends blade life.
- Tool-Free Setup & Low Maintenance: Intuitive adjustments and rugged mechanical construction ensure trouble-free daily operation.
- Straight-Through Production Flow: Front-infeed and rear-discharge configuration streamlines workstation ergonomics and material handling.
- Ideal for High-Mix Low-Volume Production: Hand-feeding eliminates bowl feeder tooling constraints, adapting instantly to odd-form packages.
Lead Forming & Geometric Parameter Specifications
Unit: mm / Custom tooling available Dimension & Bending Schematic CF-150
Callouts match specifications in the table (Click image to enlarge)
| Code | Parameter | Standard Value / Range | Engineering Notes |
|---|---|---|---|
| A | Body Length (A) | 3 ~ 25 mm | Suitable for any standing bulk parts |
| H | Lead Length (H) | Min. 3 mm | Minimum lead length after cutting |
| W | Wire Diameter (W) | 0.35 ~ 1.2 mm | Special cutting method, long tool life |
| CAP | Working Capacity | 9,000 pcs/Hour | Front feeding, back discharging |
